Name: Supermicro Hyper SuperServer AS-2126HS-TN 2U Rackmount Server with AMD EPYC 9005/9004 Processors, 6TB DDR5 Memory, 3 GPUs, and 2000W Titanium Power
Brand: Beijing Core-Net Techonology Co., Limited
SKU: AS-2126HS-TN
Price: 2,850.00 USD
Availability: InStock

Detail Information

Form Factor:	2U Rackmount	Processor:	AMD EPYC™ 9005/9004 Series Processors
Max GPU Count:	Up To 3 Double-width GPUs	Max Memory (1DPC):	Up To 6TB 6400MT/s ECC DDR5 RDIMM (AMD EPYC™ 9005 Series Processor)
Drive Bays Configuration:	Default: Total 8 Bays	Power Supply:	2x 2000W Redundant (1 + 1) Titanium Level (96%) Power Supplies
Gross Weight:	75 Lbs (34 Kg)	Net Weight:	45 Lbs (20.5 Kg)
Available Color:	Silver
Highlight:	6TB DDR5 Memory Supermicro Hyper SuperServer , 3 Double-Width GPUs 2U Rackmount Server , 2000W Titanium Power AMD EPYC Server

Product Description

Supermicro Hyper SuperServer AS-2126HS-TN

Key Applications

Virtualization, Software-defined Storage, AI Inference and Machine Learning, Cloud Computing, Enterprise Server, High Performance Computing (HPC)

Key Features

Dual AMD EPYC™ 9005/9004 Series Processors
Support up to DDR5 24 DIMM slots (1DPC), speed up to 6400MT/s
Optional PCIe slot configurations up to 8 PCIe 5.0 x8 or 4 PCIe 5.0 x16 slots or mix and match
Flexible networking options with 1 AIOM networking slot (OCP NIC 3.0 compatible)
Up to 24 front hot-swap 2.5" NVMe/SATA drive bays
2 M.2 PCIe 3.0 NVMe slots
Capabilities for GPU and CXL 2.0 support
Dual 1600W / 2000W / 2600W Redundant Titanium Level power supplies

Form Factor	2U Rackmount Enclosure: 437 x 88.9 x 806.2mm (17.2" x 3.5" x 31.74") Package: 672 x 253 x 1100mm (26.46" x 9.96" x 43.31")
Processor	Dual AMD EPYC™ 9005/9004 Series Processors Up to 384C/768T
GPU	Max GPU Count: Up to 3 double-width GPUs Supported GPU: NVIDIA PCIe: H100 NVL, RTX 6000 Ada Generation, L4 AMD PCIe: Instinct™ MI210 GPU-GPU Interconnect: PCIe
System Memory	Slot Count: 24 DIMM slots Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM (AMD EPYC™ 9005 Series Processor) Max Memory (1DPC): Up to 6TB 4800MT/s ECC DDR5 RDIMM (AMD EPYC™ 9004 Series Processor)
Drive Bays Configuration	Default: Total 8 bays - 8 front hot-swap 2.5" NVMe/SATA drive bays Option A: Total 24 bays - 24 front hot-swap 2.5" NVMe/SATA drive bays (*NVMe/SATA support may require additional storage controller and/or cables) M.2: 2 M.2 PCIe 3.0 x4 NVMe slots (M-key 2280/22110)
Expansion Slots	PCI-Express (PCIe) Configuration: Option A: 4 PCIe 5.0 x16 FHFL double-width slots + 1 PCIe 5.0 x16 AIOM slot (OCP 3.0 compatible) Option B: 8 PCIe 5.0 x8 (in x16) FHFL slots + 1 PCIe 5.0 x16 AIOM slot (OCP 3.0 compatible) CXL Support: Up to 4 CXL 2.0 x16 devices
On-Board Devices	Chipset: System on Chip Network Connectivity: Via AIOM IPMI: Support for Intelligent Platform Management Interface v.2.0 with virtual media over LAN and KVM-over-LAN support
Power Supply	2x 2000W Redundant (1 + 1) Titanium Level (96%) power supplies
Dimensions and Weight	Weight: Gross Weight: 75 lbs (34 kg), Net Weight: 45 lbs (20.5 kg) Available Color: Silver

Product Images

Tag:

Place of Origin:	China
Brand Name:	Supermicro
Model Number:	AS-2126HS-TN

Minimum Order Quantity:	1/set
Delivery Time:	2-3 work days
Payment Terms:	T/T
Supply Ability:	50pcs per week

Supermicro Hyper SuperServer AS-2126HS-TN 2U Rackmount Server with AMD EPYC 9005/9004 Processors, 6TB DDR5 Memory, 3 GPUs, and 2000W Titanium Power

6TB DDR5 Memory Supermicro Hyper SuperServer

3 Double-Width GPUs 2U Rackmount Server

2000W Titanium Power AMD EPYC Server
