Name: Supermicro Hyper SuperServer SYS-120H-TNR 1U Rackmount Server with 3rd Gen Intel Xeon Scalable Processors 32 DIMM Slots and 8 Hot-Swap NVMe/SATA/SAS Drive Bays
Brand: Beijing Core-Net Techonology Co., Limited
SKU: SYS-120H-TNR
Price: 2,850.00 USD
Availability: InStock

Detail Information

Form Factor:	1U Rackmount	Processor:	3rd Gen Intel® Xeon® Scalable Processors
GPU:	Up To 2 Double-width GPUs	System Memory:	Slot Count: 32 DIMM Slots
Expansion Slots:	Default 1 PCIe 4.0 X16 FHHL Slot 2 PCIe 4.0 X16 FH/10.5"L Slots 1 PCIe 4.0 X16 AIOM Slot (OCP 3.0 Compatible)	Drive Bays Configuration:	Default: Total 8 Bays
Power Supply:	2x 1200W Redundant Titanium Level (96%) Hot-plug Power Supplies	Gross Weight:	49 Lbs (18.8 Kg)
Net Weight:	34 Lbs (8.7 Kg)	Available Color:	N/A
Highlight:	3rd Gen Intel Xeon Scalable Processors Supermicro Hyper SuperServer , 32 DIMM Slots 1U Rackmount Server , 8 Hot-Swap NVMe/SATA/SAS Drive Bays Storage Server

Product Description

Supermicro Hyper SuperServer SYS-120H-TNR

Key Applications

Virtualization
Software-defined Storage
AI Inference and Machine Learning
Cloud Computing
Enterprise Server

Key Features

Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable Processors
32 DIMM Slots supporting up to 8TB DRAM
Up to 8TB Intel® Optane™ Persistent Memory (up to 12TB with DRAM)
3200/2933/2666 ECC DDR4 LRDIMM/RDIMM
Intel® Optane™ Persistent Memory 200 series support
3 PCIe 4.0 x16 slots with GPU/Accelerator card support
Flexible networking with AIOM slot (OCP NIC 3.0 compatible)
8x 2.5" hot-swap NVMe/SATA/SAS drive bays with optional expansion
2x internal M.2 NVMe/SATA drive slots
Optional RAID support via storage add-on card
8 heavy duty hot-swap fans with optimal speed control

Technical Specifications

Form Factor	1U Rackmount Enclosure: 437 x 43 x 747mm (17.2" x 1.7" x 29.4") Package: 605 x 206 x 1032mm (23.8" x 8.1" x 40.6")
Processor	Dual Socket P+ (LGA-4189) 3rd Gen Intel® Xeon® Scalable processors Up to 40C/80T; Up to 60MB Cache per CPU
GPU	Up to 2 double-width GPUs
System Memory	Slot Count: 32 DIMM slots Max Memory (2DPC): Up to 8TB 3200MT/s ECC DDR4 Supports Intel® Optane™ persistent memory 200 series
Drive Bays Configuration	Default: Total 8 bays - 8 front hot-swap 2.5" NVMe/SAS/SATA* drive bays Option A: Total 12 bays - 12 front hot-swap 2.5" NVMe/SAS/SATA* drive bays (*NVMe/SAS/SATA support may require additional storage controller and/or cables) M.2: 2 M.2 NVMe/SATA slots (M-key 2280/22110)
Expansion Slots	Default 1 PCIe 4.0 x16 FHHL slot 2 PCIe 4.0 x16 FH/10.5"L slots 1 PCIe 4.0 x16 AIOM slot (OCP 3.0 compatible)
Power Supply	2x 1200W Redundant Titanium Level (96%) Hot-plug power supplies
Dimensions and Weight	Weight: Gross Weight: 49 lbs (22.2 kg) Net Weight: 34 lbs (15.4 kg)

Product Images

Tag:

Place of Origin:	China
Brand Name:	Supermicro
Model Number:	SYS-120H-TNR

Minimum Order Quantity:	1/set
Delivery Time:	2-3 work days
Payment Terms:	T/T
Supply Ability:	50pcs per week
