Supermicro AS-4124GS-TNR 4U GPU Server with Dual AMD EPYC™ 7003/7002 Series Processors

• Dual AMD EPYC™ 7003/7002 Series Processors
  (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer)*
• Socket SP3
• Up to 128 Cores (64 per CPU)

• Supported GPUs

  8 Double-Width/Single-Width PCI-E 3.0/4.0 x16 Card (Full Height Full Length)
  NVIDIA A100, V100, A40, T4, Quadro RTX, AMD Instinct
  Supports both active and passive cooled GPUs

  CPU-GPU Interconnect

  PCI-E Gen 4 x16 Direct Connect CPU-GPU Dual-Root

  GPU-GPU Interconnect

  NVIDIA® NVLink™ Bridge (Optional), AMD Infinity Fabric (optional)

Memory Capacity

32 DIMM slots*
Up to 8TB 3DS ECC DDR4-3200MHz RDIMM/LRDIMM

Memory Type

3200MHz ECC DDR4 RDIMM/LRDIMM

Hot-swap

Up to 24x 2.5" SAS/SATA drive bays
2x 2.5" SATA supported natively*
4x 2.5" NVMe (Gen3 only) supported natively
RAID controller option available for 24 HDDs

9 PCI-E 4.0 x16 (FHFL) slots
or 10 PCI-E 4.0 x16 (FHFL) slots without NVMe devices

(W x H x L)

• 73.5 x 40 x 203 mm
