Supermicro AS-4145GH-TNMR 4U GPU Server With Quad AMD Instinct™ MI300A Accelerators

Quad Socket SH5

AMD Instinct™ MI300A Accelerated Processing Units (APUs)

Max GPU Count: 4 onboard GPUs

Supported GPU: AMD: Instinct™ MI300A APU

GPU-GPU Interconnect: AMD Infinity Fabric™ Link

Slot Count: Onboard Memory

Max Memory: Up to 512GB non-ECC HBM3

Default: Total 8 bays

8 front fixed 2.5" NVMe drive bays

Option A: Total 16 bays 16 front fixed 2.5" NVMe drive bays

Option B: Total 24 bays 24 front fixed 2.5" SAS*/SATA* drive bays (*SAS/SATA support may require additional storage controller and/or cables, please see the optional parts list for details) M.2: 2 M.2 NVMe slots (M-key 2280/22110)

Default

4 PCIe 5.0 x16 FHHL slots 2 PCIe 5.0 x8 FHHL slots

Option A* 4 PCIe 5.0 x16 FHHL slots 6 PCIe 5.0 x8 FHHL slots 2 PCIe 5.0 x8 AIOM slots (OCP 3.0 compatible)

Option B* 6 PCIe 5.0 x16 FHHL slots 2 PCIe 5.0 x16 AIOM slots (OCP 3.0 compatible)

Option C* 14 PCIe 5.0 x8 FHHL slots 2 PCIe 5.0 x8 AIOM slots (OCP 3.0 compatible)

Option D* 4 PCIe 5.0 x16 FHHL slots 2 PCIe 5.0 x8 FHHL slots 2 PCIe 5.0 x8 AIOM slots (OCP 3.0 compatible)

Weight: Gross Weight: 158.07 lbs (71.7 kg) Net Weight: 120.59 lbs (54.7 kg)

Available Color: No Paint
