| Place of Origin: | China |
|---|---|
| Brand Name: | Supermicro |
| Model Number: | AS-4124GQ-TNMI 4U GPU Server |
| Minimum Order Quantity: | 1/set |
| Delivery Time: | 2-3 work days |
| Payment Terms: | T/T |
| Supply Ability: | 50pcs per week |
| Form Factor: | 4U Rackmount | Processor: | Intel® Xeon® 6900 Series Processors With P-cores |
|---|---|---|---|
| GPU: | Supported GPU: NVIDIA PCIe: H100 NVL, H200 NVL (141GB), L40S | System Memory: | 24 DIMM Slots |
| Expansion Slots: | 8 PCIe 5.0 X16 FH Double-width Slots 4 PCIe 5.0 X16 HHHL Slots | Drive Bays Configuration: | 8 Front Hot-swap E1.S NVMe Drive Bays |
| Power Supply: | 4x 3200W Redundant (3 + 1) Titanium Level (96%) Power Supplies | Available Color: | Silver |
| Highlight: | Intel Xeon 6900 GPU Server,Supermicro SYS-422GL-NR,Supermicro 4U GPU Server |
||
Key Applications:
High Performance Computing, AI/Deep Learning Training, Industrial Automation, Retail, Healthcare, Conversational AI, Business Intelligence & Analytics, Drug Discovery, Climate and Weather Modeling, Finance & Economics,
Key Features High density:
Dual Socket Intel® Xeon® 6 6900 series processors with P-cores up to 500W; Support for up to 8 PCIe GPU accelerator cards; Supports 24x ECC DDR5 DIMMs at 6400 MT/s; 8x PCIe 5.0 x16 for GPU 4x PCIe 5.0 x16 for NIC Additional 1x PCIe 5.0 x16 for NIC/DPU (Via CPU); Up to 8 front hot-swap E1.S NVMe drive bays;
| Form | Supermicro SYS-422GL-NR 4U GPU Server |
| Processors |
Dual Socket BR (LGA-7529) Intel® Xeon® 6900 series processors with P-cores 72C/144T |
| GPU |
Max GPU Count: Up to 8 double-width GPUs Supported GPU: NVIDIA PCIe: H100 NVL, H200 NVL (141GB), L40S CPU-GPU Interconnect: PCIe 5.0 x16 Switch Dual-Root GPU-GPU Interconnect: NVIDIA® NVLink® Bridge (optional) |
| System Memory |
Slot Count: 24 DIMM slots Max Memory (1DPC): 6.0TB 6400MT/s ECC DDR5 RDIMM Max Memory (1DPC): 6.0TB 8800MT/s ECC DDR5 MRDIMM |
| Drive Bays Configuration |
Default: Total 8 bays 8 front hot-swap E1.S NVMe drive bays |
| Expansion slots |
PCI-Express (PCIe) Configuration: Default 8 PCIe 5.0 x16 FH double-width slots 4 PCIe 5.0 x16 HHHL slots Option A 1 PCIe 5.0 x16 FHHL slot M.2: 2 M.2 PCIe 4.0 x4 NVMe slots (M-key 2280(default)) |
| Power Supply | 4x 3200W Redundant (3 + 1) Titanium Level (96%) power supplies |
| Dimensions and Weight |
Weight: Gross Weight: 96.45 lbs (43.75 kg) Net Weight: 49.5 lbs (22.45 kg) Available Color: Silver |
