| Place of Origin: | China |
|---|---|
| Brand Name: | Supermicro |
| Model Number: | SYS-422GA-NBRT-LCC 4U GPU Server |
| Minimum Order Quantity: | 1/set |
| Delivery Time: | 2-3 work days |
| Payment Terms: | T/T |
| Supply Ability: | 50pcs per week |
| Form Factor: | 4U Rackmount | Processor: | Intel® Xeon® 6900 Series Processors With P-cores |
|---|---|---|---|
| GPU: | Supported GPU: NVIDIA SXM: HGX B200 8-GPU (180GB) | System Memory: | 24 DIMM Slots |
| Expansion Slots: | Default 10 PCIe 5.0 X16 LP Slots 2 PCIe 5.0 X16 FHHL Slots | Drive Bays Configuration: | 8 Front Hot-swap 2.5" NVMe Drive Bays |
| Power Supply: | 2x 2600W Redundant (1 + 1) Titanium Level (96%) Power Supplies | Available Color: | Silver |
Key Applications:
Scientific Research, Conversational AI, Business Intelligence & Analytics, Drug Discovery, Finance Services and Fraud Detection, AI/Deep Learning Training and Inference, Large Language Model (LLM) and Generative AI, High Performance Computing (HPC), Autonomous Vehicle Technologies,
Key Features High density:
Complete liquid-cooled rack integration is required for purchase; Dual Intel® Xeon® 6900 series processors with P-cores; 8x NVIDIA SXM B200 GPUs, 1.4TB of GPU memory space; 24x DIMM slots, ECC RDIMM / MRDIMM DDR5 up to 8800MT/s (1DPC); 10x PCIe 5.0 x16 LP, 2x PCIe 5.0 x16 FHHL slots; 8x front hot-swap 2.5" NVMe U.2, 2x front hot-swap NVMe M.2; 2x 10GbE RJ-45, 1x Dedicated BMC/IPMI;
| Form | Supermicro SYS-422GA-NBRT-LCC 4U GPU Server |
| Processors |
Dual Socket BR (LGA-7529) Intel® Xeon® 6900 series processors with P-cores Up to 128C/256T; Up to 504MB Cache per CPU |
| GPU |
Max GPU Count: 8 onboard GPUs Supported GPU: NVIDIA SXM: HGX B200 8-GPU (180GB) CPU-GPU Interconnect: PCIe 5.0 x16 CPU-to-GPU Interconnect GPU-GPU Interconnect: NVIDIA® NVLink® with NVSwitch™ |
| System Memory |
Slot Count: 24 DIMM slots Max Memory (1DPC): Up to 6TB 6400MT/s ECC DDR5 RDIMM Max Memory (1DPC): Up to 6TB 8800MT/s ECC DDR5 MRDIMM |
| Drive Bays Configuration |
Default: Total 8 bays 8 front hot-swap 2.5" NVMe drive bays M.2: 2 M.2 NVMe slots (M-key) |
| Expansion slots |
Default 10 PCIe 5.0 x16 LP slots 2 PCIe 5.0 x16 FHHL slots |
| Power Supply | 4x 6600W Redundant (2 + 2) Titanium Level (96%) power supplies |
| Dimensions and Weight |
Weight: Gross Weight: 236 lbs (107 kg) Net Weight: 203 lbs (92 kg) Available Color: Silver |
