| Place of Origin: | China |
|---|---|
| Brand Name: | Supermicro |
| Model Number: | AS-2114GT-DPNR |
| Minimum Order Quantity: | 1/set |
| Delivery Time: | 2-3 work days |
| Payment Terms: | T/T |
| Supply Ability: | 50pcs per week |
| Form Factor: | 2U Rackmount | Processor: | AMD EPYC™ 7002/7003 Series Processors |
|---|---|---|---|
| GPU: | Supported GPU: NVIDIA PCIe: L40, RTX A6000, RTX A4500, RTX A4000, A40, A16, A2, A100, A10 | System Memory: | Up To 2TB ECC DDR4 RDIMM/LRDIMM |
| Expansion Slots: | Default 1 PCIe 4.0 X16 FHHL Slot 1 PCIe 4.0 X16 FHFL Slot 1 PCIe 4.0 X8 AIOM Slot (OCP 3.0 Compatible) | Drive Bays Configuration: | 2 Front Hot-swap 2.5" NVMe Drive Bays |
| Power Supply: | 2x 2600W Redundant (1 + 1) Titanium Level (96%) Power Supplies | Available Color: | Black Front & Silver Body |
Key Applications:
AI Inference and Machine Learning, Industrial Automation, Retail, Smart Medical Expert Systems, Media/Video Streaming, GPU Virtualization (VDI),
Key Features High density:
Two hot-pluggable systems (nodes) in a 2U form factor. Each node supports the following:; AMD Ryzen™ Threadripper™ PRO 5000WX/3000WX Series Processor, up to 64 Cores; 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs; 2 PCIe 4.0 x16 external slots + 1 PCIe 4.0 x8 AIOM slot (or optional x16 AIOM with additional parts);
| Form | Supermicro AS-2114GT-DPNR 2U GPU Server |
| Processors | Single Socket SP3 AMD EPYC™ 7002/7003 Series Processors |
| GPU | Max GPU Count: Up to 2 double-width or 4 single-width GPUs |
| System Memory | Slot Count: 8 DIMM slots Max Memory (1DPC): Up to 2TB ECC DDR4 RDIMM/LRDIMM |
| Drive Bays Configuration | Default: Total 2 bays 2 front hot-swap 2.5" NVMe drive bays |
| Expansion slots | Default |
| Power Supply | 2x 2600W Redundant (1 + 1) Titanium Level (96%) power supplies |
| Dimensions and Weight | Weight: Gross Weight: 60 lbs (27.21 kg) |
