| Place of Origin: | China |
|---|---|
| Brand Name: | Supermicro |
| Model Number: | AS-2114GT-DNR |
| Minimum Order Quantity: | 1/set |
| Delivery Time: | 2-3 work days |
| Payment Terms: | T/T |
| Supply Ability: | 50pcs per week |
| Form Factor: | 2U Rackmount | Processor: | AMD EPYC™ 7002/7003 Series Processors |
|---|---|---|---|
| GPU: | Up To 2 Double-width Or 4 Single-width GPUs | System Memory: | Up To 2TB 3200MT/s ECC DDR4 RDIMM/LRDIMM |
| Expansion Slots: | 4 PCIe 4.0 X16 INTERNAL Slots 1 PCIe 4.0 X16 FHHL Slot 1 PCIe 4.0 X16 FHFL Slot 1 PCIe 4.0 X8 AIOM Slot (OCP 3.0 Compatible) | Power Supply: | 2x 2600W Redundant (1 + 1) Titanium Level (96%) Power Supplies |
| Available Color: | Black Front & Silver Body |
Key Applications:
AI Inference and Machine Learning, Media/Video Streaming, Industrial Automation, Retail, Cloud Gaming, Smart Medical Expert Systems,
Key Features High density:
Two hot-pluggable systems (nodes) in a 2U form factor. Each node supports the following:; Single AMD EPYC™ 7003/7002 Series Processor (The latest AMD EPYC™ 7003 Series Processor with AMD 3D V-Cache™ Technology requires BIOS version 2.3 or newer); 2TB Registered ECC DDR4 3200MHz SDRAM in 8 DIMMs; Up to 6 PCIe 4.0 x16 (4 internal + 2 external) slots, 1 PCIe 4.0 x8 AIOM slot M.2 Interface: 2 PCIe 4.0 x4 M.2 Form Factor: 2280, 22110 M.2 Key: M-key; 2 Front hot-swap 2.5" PCIe 4.0 NVMe drive bays;
| Form | Supermicro AS-2214GT-DNR 2U GPU Server |
| Processors | Single Socket SP3 AMD EPYC™ 7002/7003 Series Processors |
| GPU | Max GPU Count: Up to 2 double-width or 4 single-width GPUs |
| System Memory | Slot Count: 8 DIMM slots Max Memory (1DPC): Up to 2TB 3200MT/s ECC DDR4 RDIMM/LRDIMM |
| Drive Bays Configuration | Default: Total 2 bays 2 front hot-swap 2.5" NVMe drive bays |
| Expansion slots | Default 4 PCIe |
| Power Supply | 2x 2600W Redundant (1 + 1) Titanium Level (96%) power supplies |
| Dimensions and Weight | Weight: Gross Weight: 60 lbs (27.21 kg) Net Weight: 55 lbs (24.94 kg) Available Color: Black Front & Silver Body |
