Xfusion FusionServer 2158H V8 2U Rack Server with 4th Gen AMD EPYC 9004, 10 PCIe Expansion Slots, and 2 OCP 3.0 NICs

Xfusion FusionServer 2158H V8 2U Rack Server with 4th Gen AMD EPYC 9004, 10 PCIe Expansion Slots, and 2 OCP 3.0 NICs
Xfusion FusionServer 2158H V8 2U Rack Server with 4th Gen AMD EPYC 9004, 10 PCIe Expansion Slots, and 2 OCP 3.0 NICs Xfusion FusionServer 2158H V8 2U Rack Server with 4th Gen AMD EPYC 9004, 10 PCIe Expansion Slots, and 2 OCP 3.0 NICs Xfusion FusionServer 2158H V8 2U Rack Server with 4th Gen AMD EPYC 9004, 10 PCIe Expansion Slots, and 2 OCP 3.0 NICs
Basic Information
Place of Origin: China
Brand Name: Xfusion
Model Number: 2158H V8
Minimum Order Quantity: 1/set
Delivery Time: 2-3 work days
Payment Terms: T/T
Supply Ability: 50pcs per week
Get Best Price Contact Now
Detail Information
Form Factor: 2U Rack Server Processor: 1 X 4th Gen AMD EPYCTM 9004 (Genoa) Or 5th-Gen EPYC™ 9005 Series (Turin) Processor With Up To 500 W TDP Per Processor
Network: 2 X OCP 3.0 NICs, Which Can Be Configured As Required; Support Hot Swap And PCIe 5.0 PCIe Expansion: 10 X PCIe Expansion Slots; Support PCIe 5.0
Security: Power-on Password, Administrator Password, Trusted Platform Module (TPM) 2.0, Security Panel, Secure Boot, And Chassis Cover Opening Detection Operating Temperature: 5°C To 45°C (41°F To 113°F), Compliant With ASHRAE Classes A1 To A4
Dimensions (H X W X D): 86.1 Mm X 447 Mm X 798 Mm (3.39 In. X 17.60 In. X 31.42 In.)

Product Description

Form Factor 2U rack server
Processor 1 x 4th Gen AMD EPYCTM 9004 (Genoa) or 5th-Gen EPYC™ 9005 series (Turin) processor with up to 500 W TDP per processor
Local storage Hot-swappable and flexible drive configurations:
  • 8 x 2.5″ SAS/SATA/NVMe drives
  • 8 x 3.5″ SAS/SATA/NVMe drives
  • 12 x 3.5″ SAS/SATA/NVMe drives
  • 24 x 2.5″ drives (16 x NVMe drives + 8 x SAS/SATA drives)
  • 2 x M.2 SSDs (SAS/SATA)
RAID RAID 0, 1, 10, 5, 50, 6, and 60; supercapacitor for cache data protection against power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
Network 2 x OCP 3.0 NICs, which can be configured as required; support hot swap and PCIe 5.0
PCIe Expansion 10 x PCIe expansion slots; support PCIe 5.0
GPU Card Fan Module 4 x dual-width GPU cards and 1 x dual-width DPU card
Four 80 x 80 or six 60 x 60 hot-swappable counter-rotating fan modules in N+1 redundancy
PSU 2 x PSUs in 1+1 redundancy:
  • 900 W/1500 W/2000 W Platinum AC PSUs
  • 900 W/2000 W/3000 W Titanium AC PSUs
  • 1200 W -48 V DC PSUs
  • 1500 W 380 V high-voltage DC PSUs
Management The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening.
  • The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management interface based on HTML5/VNC KVM, and supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management.
  • It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies, enabling intelligent, automatic, visualized, and refined management throughout the lifecycle.
OS xFusion FusionOS, SUSE Linux Enterprise Server, VMware vSphere, Red Hat Enterprise Linux, Oracle, and Ubuntu
Security Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection
Operating temperature 5°C to 45°C (41°F to 113°F), compliant with ASHRAE Classes A1 to A4
Certification CE, UL, CCC, FCC, VCCI, and RoHS
Installation Suite L-shaped, adjustable, and holding rails
Dimensions (H x W x D) 86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.)
