| Place of Origin: | China |
|---|---|
| Brand Name: | Cisco |
| Certification: | CE |
| Model Number: | N9K-C9504 |
| Minimum Order Quantity: | 2 pcs |
| Packaging Details: | Carton |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 70 PCS Per week |
| Brand: | Cisco | Products Status: | Stock |
|---|---|---|---|
| Products Name: | N9K-C9504 | Warranty: | 1 Year |
| Highlight: | N9K C9504,Cisco Nexus 9504,Nexus 9504 |
||
| Cisco Nexus 9504 Chassis | Cisco Nexus 9508 Chassis | Cisco Nexus 9516 Chassis | |
| Number of line card slots | 4 | 8 | 16 |
| Dimensions (H x W x D) |
12.25 x 17.50 x 33.15 in. (31.1 x 44.50 x 84.20 cm) |
22.70 x 17.50 x 31.76 in. (57.78 x 44.50 x 80.67 cm) |
36.70 x 17.50 x 31.76 in. (93.41 x 44.50 x 80.67 cm) |
| Weight | 84 lb (38.2 kg) | 150 lb (68.2 kg) | 192 lb (87.3 kg) |
| Rack Units | 7 | 13 | 21 |
| Mean Time Between Failure (MTBF) Hours | 1,038,080 | 928,910 | 680,000 |
| Operating temperature | 32 to 104°F (0 to 40°C) | ||
| Nonoperating temperature | -40 to 158°F (-40 to 70°C) | ||
| Humidity | 5 to 95% (noncondensing) | ||
| Altitude | 0 to 13,123 ft (0 to 4,000m) | ||
| Regulatory compliance | Products should comply with CE Markings according to directives 2004/108/EC and 2006/95/EC | ||
| Safety |
UL 60950-1 Second Edition CAN/CSA-C22.2 No. 60950-1 Second Edition EN 60950-1 Second Edition IEC 60950-1 Second Edition AS/NZS 60950-1 GB4943 |
||
| EMC: Emissions |
47CFR Part 15 (CFR 47) Class A AS/NZS CISPR22 Class A CISPR22 Class A EN55022 Class A ICES003 Class A VCCI Class A EN61000-3-2 EN61000-3-3 KN22 Class A CNS13438 Class A |
||
| EMC: Immunity |
EN55024 CISPR24 EN300386 KN 61000-4 series |
||
| RoHS | The product is RoHS-6 compliant with exceptions for leaded-ball grid-array (BGA) balls and lead press-fit connectors. | ||
