| Total 10/100/1000, Multigigabit Copper Or SFP Fiber: | 48 Ports Data | Uplink Configuration: | Modular Uplinks |
|---|---|---|---|
| Default AC Power Supply: | 350W AC | Switching Capacity: | 256 Gbps |
| Switching Capacity With Stacking: | 736 Gbps | Forwarding Rate: | 190.47 Mpps |
| Forwarding Rate With Stacking: | 547.62 Mpps | ||
| Highlight: | 48 ports data Cisco Catalyst 9300 Series Switch,256 Gbps switching capacity C9300-48T Switch,Modular uplinks Catalyst 9300 Switch |
||
| Specification | Details |
|---|---|
| Total 10/100/1000, Multigigabit copper or SFP fiber | 48 ports data |
| Uplink configuration | Modular uplinks |
| Default AC power supply | 350W AC |
| Switching capacity | 256 Gbps |
| Switching capacity with stacking | 736 Gbps |
| Forwarding rate | 190.47 Mpps |
| Forwarding rate with stacking | 547.62 Mpps |
| Dimensions (H x W x D) in inches (Chassis only) | 1.73 x 17.5 x 16.1 |
| Dimensions (H x W x D) in inches (With default power supply) | 1.73 x 17.5 x 17.7 |
| Dimensions (H x W x D) in inches (With 1100W power supply) | 1.73 x 17.5 x 19.2 |
