| Total 10/100/1000, Multigigabit Copper Or SFP Fiber: | 24 Ports Data | Uplink Configuration: | 4x 10G/1G Fixed Uplinks |
|---|---|---|---|
| Default AC Power Supply: | 350W AC | Switching Capacity: | 128 Gbps |
| Switching Capacity With Stacking: | 448 Gbps | Forwarding Rate: | 95.23 Mpps |
| Forwarding Rate With Stacking: | 333.33 Mpps | Dimensions (H X W X D) In Inches(Chassis Only ): | 1.73 X 17.5 X 16.1 |
| Highlight: | 24 ports data Cisco Catalyst 9300X Switch,4x 10G/1G fixed uplinks Catalyst 9300 Series Switch,128 Gbps switching capacity C9300L-24T-4X Switch |
||
| Model | C9300L-24T-4X |
| Total 10/100/1000, Multigigabit copper or SFP fiber | 24 ports data |
| Uplink configuration | 4x 10G/1G fixed uplinks |
| Default AC power supply | 350W AC |
| Switching capacity | 128 Gbps |
| Switching capacity with stacking | 448 Gbps |
| Forwarding rate | 95.23 Mpps |
| Forwarding rate with stacking | 333.33 Mpps |
| Dimensions (H x W x D) in inches (Chassis only) | 1.73 X 17.5 X 16.1 |
| Dimensions (H x W x D) in inches (With default power supply) | 1.73 X 17.5 X 17.7 |
| Dimensions (H x W x D) in inches (With 1100W power supply) | 1.73 X 17.5 X 19.2 |
