Supermicro SYS-212GB-NR 2U GPU Server with Intel® Xeon® 6700-series processors with P-cores

Single Socket E2 (LGA-4710)

Intel® Xeon® 6700-series processors with P-cores

Up to 80C/160T

Max GPU Count: Up to 4 double-width GPUs
Supported GPU: NVIDIA PCIe: NVIDIA RTX PRO™ 6000 Blackwell Server Edition, H200 NVL (141GB)
CPU-GPU Interconnect: PCIe 5.0 x16 CPU-to-GPU Interconnect
GPU-GPU Interconnect: NVIDIA® NVLink® Bridge (optional)

Slot Count: 16 DIMM slots/8 Channels

Max Memory (1DPC): Up to 1TB 6400MT/s ECC DDR5 RDIMM

Max Memory (1DPC): Up to 512GB 8000MT/s ECC DDR5 MRDIMM

Max Memory (2DPC): Up to 2TB 5200MT/s ECC DDR5 RDIMM

Default: Total 4 bays

4 front hot-swap E1.S NVMe drive bays

M.2: 2 M.2 PCIe 5.0 x2 NVMe slots (M-key 2280/22110)

PCI-Express (PCIe) Configuration: Default
4 PCIe 5.0 x16 FHFL double-width slots
3 PCIe 5.0 x16 FHFL slots M.2: 2 M.2 PCIe 5.0 x2 NVMe slots (M-key 2280/22110)

Weight: Gross Weight: 84 lbs (38 kg) Net Weight: 66 lbs (30 kg)
Available Color: Black front & silver body
