Xfusion FusionServer 2258H V8 2U Rack Server with 5th-Gen EPYC™ 9005 Series Processor, 24 DDR5 DIMMs, and 10 PCIe 5.0 Expansion Slots

Large Image : Xfusion FusionServer 2258H V8 2U Rack Server with 5th-Gen EPYC™ 9005 Series Processor, 24 DDR5 DIMMs, and 10 PCIe 5.0 Expansion Slots

Product Details:

Place of Origin:	China
Brand Name:	Xfusion
Model Number:	2258H V8

Payment & Shipping Terms:

Minimum Order Quantity:	1/set
Delivery Time:	2-3 work days
Payment Terms:	T/T
Supply Ability:	50pcs per week

Contact Now

Xfusion FusionServer 2258H V8 2U Rack Server with 5th-Gen EPYC™ 9005 Series Processor, 24 DDR5 DIMMs, and 10 PCIe 5.0 Expansion Slots

Description

Form Factor:	2U Rack Server	Processor:	2 X5th-Gen EPYC™ 9005 Series (Turin) Processor With Up To 500 W TDP Per Processor
Memory:	24 X DDR5 DIMMs, Delivering Up To 6400 MT/s	Network:	2 X OCP 3.0 NICs, Which Can Be Configured As Required; Support Hot Swap And PCIe 5.0
PCIe Expansion:	10 X PCIe Expansion Slots; Support PCIe 5.0	Security:	Power-on Password, Administrator Password, Trusted Platform Module (TPM) 2.0, Security Panel, Secure Boot, And Chassis Cover Opening Detection
Operating Temperature:	5°C To 45°C (41°F To 113°F), Compliant With ASHRAE Classes A1 To A4	Dimensions (H X W X D):	86.1 Mm X 447 Mm X 798 Mm (3.39 In. X 17.60 In. X 31.42 In.)
Highlight:	HUAWEI FusionServer 2258H V8 rack server , 2U rack server with EPYC 9005 processor , HUAWEI storage server with DDR5 DIMMs

Major application scenarios: IT core operations, Cloud computing, HPC

The FusionServer 2258H V8 is a next-generation 2U2P rack server designed to meet the demands of High-Performance Computing (HPC), Internet Data Center (IDC), and cloud computing.

Featuring low energy consumption, exceptional scalability, proven reliability, and ease of management and deployment, the 2258H V8 is the perfect choice for IT core operations in Internet and telecom.

Form Factor	2U rack server
Processor	2 x5th-Gen EPYC™ 9005 series (Turin) processor with up to 500 W TDP per processor
Memory	24 x DDR5 DIMMs, delivering up to 6400 MT/s
Local storage	8 x 2.5″ SAS/SATA/NVMe drives 16/24 x NVMe drives* 8 x 2.5“ NVMe drives, Support hard raid* 8 x 3.5″ SAS/SATA/NVMe drives 4 x rear-mounted 2.5“ NVMe drives 2 x M.2 SSDs (SAS/SATA)
RAID	RAID 0, 1, 10, 5, 50, 6, and 60; supercapacitor for cache data protection against power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
Network	2 x OCP 3.0 NICs, which can be configured as required; support hot swap and PCIe 5.0
PCIe Expansion	10 x PCIe expansion slots; support PCIe 5.0
GPU	Supports 4 x dual-width GPUs
Fan Module	Four 80 x 80 hot-swappable counter-rotating fan modules in N+1 redundancy
OS	xFusion FusionOS, SUSE Linux Enterprise Server, VMware vSphere, Red Hat Enterprise Linux and Rocky Linux.
Security	Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection
Operating temperature	5°C to 45°C (41°F to 113°F), compliant with ASHRAE Classes A1 to A4
Dimensions (H x W x D)	86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.)
