Huawei FusionServer 2288 V8 2U Rack Server with 4th Gen AMD EPYC 9004 Series Processors, 32 DDR5 DIMM Slots, and 10 PCIe Slots

Large Image : Huawei FusionServer 2288 V8 2U Rack Server with 4th Gen AMD EPYC 9004 Series Processors, 32 DDR5 DIMM Slots, and 10 PCIe Slots

Product Details:

Place of Origin:	China
Brand Name:	Xfusion
Model Number:	2288 V8

Payment & Shipping Terms:

Minimum Order Quantity:	1/set
Delivery Time:	2-3 work days
Payment Terms:	T/T
Supply Ability:	50pcs per week

Contact Now

Huawei FusionServer 2288 V8 2U Rack Server with 4th Gen AMD EPYC 9004 Series Processors, 32 DDR5 DIMM Slots, and 10 PCIe Slots

Description

Form Factor:	2U Rack Server	Processors:	1 X 4th Gen AMD® EPYC 9004 Series Processors (Genoa) With Up To 400 W TDP Per Processor
Memory:	32 X Memory Slots Available For DDR5 DIMMs At Up To 6400 MT/s Or MRDIMMs At Up To 8000 MT/s	Local Memory:	Hot-swappable Drives Configurations: -Up To 20 X 3.5ʺ Drives -Up To 33 X 2.5ʺ Drives -Up To 36 X E3.s SSDs* Flash Storage: 2 X M.2 SSDs, Hardware RAID, And Hot Swap
Network:	Multiple Network Expansion Capabilities; 2 X FlexIO Card Slots Dedicated For OCP 3.0 NICs, Which Can Be Configured As Required; Supporting Hot Swap And PCIe 5.0	PCIe Expansion:	Up To 10 X Standard PCIe Slots And 2 X OCP 3.0 Slots, Supporting PCle 5.0 And Cables Routing From The Front Panel
Fans:	4 X Hot-swappable Counter-rotating Fans In N+1 Redundancy	Operating Temperature:	5°C To 45°C (41°F To 113°F), Compliant With ASHRAE Classes A1/A2/A3/A4
Dimensions (H X W X D):	86.1 Mm X 447 Mm X 798 Mm (3.39 In. X 17.60 In. X 31.42 In.)
Highlight:	Huawei FusionServer 2288 V8 rack server , Huawei 2U server with AMD EPYC , Huawei storage server DDR5 DIMM slots

The FusionServer 2288 V8 is a next-generation 2U2P rack server tailored to meet the demands of AI inference, cloud computing, virtualization, High-Performance Computing (HPC), graphics processing, VDI, and big data analytics.

Offering low power consumption, unmatched scalability, solid reliability, and ease of management and deployment, the 2288 V8 is an ideal choice for addressing massive workloads in industries such as Internet, telecom, government and enterprise, finance, and manufacturing.

Technical Specification

Form Factor	2U Rack Server
Processors	1 x 4th Gen AMD® EPYC 9004 Series processors (Genoa) with up to 400 W TDP per processor
Memory	32 x memory slots available for DDR5 DIMMs at up to 6400 MT/s or MRDIMMs at up to 8000 MT/s
Local Memory	Hot-swappable drives configurations: -Up to 20 x 3.5ʺ drives -Up to 33 x 2.5ʺ drives -Up to 36 x E3.s SSDs* Flash storage: 2 x M.2 SSDs, hardware RAID, and hot swap
RAID	RAID 0, 1, 10, 1E, 5, 50, 6, or 60; supercapacitors for cache data protection from power failures; RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
Network	Multiple network expansion capabilities; 2 x FlexIO card slots dedicated for OCP 3.0 NICs, which can be configured as required; supporting hot swap and PCIe 5.0
PCle Expansion	Up to 10 x standard PCIe slots and 2 x OCP 3.0 slots, supporting PCle 5.0 and cables routing from the front panel
Fans	4 x hot-swappable counter-rotating fans in N+1 redundancy
Operating Temperature	5°C to 45°C (41°F to 113°F), compliant with ASHRAE Classes A1/A2/A3/A4
Dimension (H x W x D)	86.1 mm x 447 mm x 798 mm (3.39 in. x 17.60 in. x 31.42 in.)

Huawei FusionServer 2288 V8 2U Rack Server with 4th Gen AMD EPYC 9004 Series Processors, 32 DDR5 DIMM Slots, and 10 PCIe Slots

Tag:

nvme storage server,

huawei oceanstor dorado,

huawei storage dorado

Contact Details

Beijing Core-Net Techonology Co., Limited

Contact Person: Alisa CC

Tel: +86 18710168043
