| Bandwidth: | 8.192Tb/s | Certified Maximum: | 4K Active Nodes; 56 Switches, 19 Hops In Brocade Fabric OS® Fabrics |
|---|---|---|---|
| FICON Support: | Not Available | Frame Based ISL Trunking: | Frame-based Trunking With Up To Eight SFP+ Ports Per ISL Trunk; Up To 512Gb/s Per ISL Trunk. |
| Power: | 969W, Dual Hot-swappable Power Supplies | Size (mm): | 440(W) X 86.7(H) X 609.6(D) |
| Total Line Rate Ports: | 48 To 128 @ 64G | Fibre Channel Ports: | 128 |
| Highlight: | 128 64G line rate ports Brocade G730 Switch,8.192Tb/s bandwidth Brocade Fiber Switch,dual hot-swappable power supplies 64G Switch |
||
| Specification | Value |
|---|---|
| Lifecycle | Active |
| Access Gateway | Not available |
| Bandwidth | 8.192 Tb/s |
| Certified Maximum | 4K active nodes; 56 switches, 19 hops in Brocade Fabric OS® fabrics |
| Fibre Channel Performance | 8.5Gb/s line speed, full duplex; 10.53Gb/s line speed, full duplex; 14.025Gb/s line speed, full duplex; 28.05Gb/s line speed, full duplex; 57.8Gb/s line speed, full duplex; auto-sensing of 8, 10, 16, 32, and 64G port speeds. 10Gb/s optionally programmable to fixed port speed. |
| Fibre Channel Ports | 128 |
| FICON Support | Not available |
| Frame Based ISL Trunking | Frame-based trunking with up to eight SFP+ ports per ISL trunk; up to 512Gb/s per ISL trunk. |
| Power | 969W, dual hot-swappable power supplies |
| Size (mm) | 440(W) x 86.7(H) x 609.6(D) |
| Total Line Rate Ports | 48 to 128 @ 64G |
