| Total 10/100/1000, Multigigabit Copper Or SFP Fiber: | 12 Ports 25G/10G/1G SFP28 | Uplink Configuration: | Modular Uplinks |
|---|---|---|---|
| Default AC Power Supply: | 715W AC | Switching Capacity: | 1000 Gbps |
| Switching Capacity With Stacking: | 2000 Gbps | Forwarding Rate: | 744.04 Mpps |
| Forwarding Rate With Stacking: | 1488 Mpps | ||
| Highlight: | 12 ports 25G/10G/1G SFP28 Cisco Catalyst 9300 Series Switch,1000 Gbps switching capacity C9300X-12Y Switch,Modular uplinks Catalyst 9300X Switch |
||
| Specification | Details |
|---|---|
| Total 10/100/1000, Multigigabit copper or SFP fiber | 12 ports 25G/10G/1G SFP28 |
| Uplink configuration | Modular uplinks |
| Default AC power supply | 715W AC |
| Switching capacity | 1000 Gbps |
| Switching capacity with stacking | 2000 Gbps |
| Forwarding rate | 744.04 Mpps |
| Forwarding rate with stacking | 1488 Mpps |
| Dimensions (H x W x D) in inches (Chassis only) | 1.73 x 17.5 x 16.1 |
| Dimensions (H x W x D) in inches (With default power supply) | 1.73 x 17.5 x 17.6 |
| Dimensions (H x W x D) in inches (With 1100W power supply) | 1.73 x 17.5 x 19.2 |
