| Product Model: | CloudEngine S5735-S24PN4XE-V2 | Forwarding Performance: | 144 Mpps |
|---|---|---|---|
| Switching Capacity: | 248 Gbps/520 Gbps | PoE: | Supported, PoE+ |
| Power Module: | N+1 Backup | Chassis Height: | 1U |
| Chassis Weight(including Packaging): | 11.98kg | Power Supply Type: | 600 W AC PoE 1000 W AC PoE 1000 W DC PoE |
| Highlight: | 144 Mpps Forwarding Performance HUAWEI CloudEngine Switch,248 Gbps/520 Gbps Switching Capacity HUAWEI Network Switch,N+1 Power Module Backup HUAWEI S5735-S24PN4XE-V2 |
||
| Product Model | CloudEngine S5735-S24PN4XE-V2 |
|---|---|
| Forwarding Performance | 144 Mpps |
| Switching Capacity | 248 Gbps/520 Gbps |
| Fixed Ports | 24 x 10/100/1000/2.5GE Base-T ports, 4 x 10 GE SFP+ ports, 2 x 12GE stack ports |
| PoE | Supported, PoE+ |
| Power Module | N+1 backup |
| VLAN | 4094 VLANs Voice VLAN MUX VLAN VLAN assignment based on MAC addresses, protocols, IP subnets, policies, and ports |
| IP Routing | Static routes, RIP, RIPng, OSPF, OSPFv3, IS-IS, IS-ISv6, BGP, BGP4+, VRRP, VRRP6, ECMP, routing policies, and policy-based routing |
| Chassis height | 1U |
| Chassis weight (including packaging) | 11.98kg |
