| Place of Origin: | China |
|---|---|
| Brand Name: | FusionServer |
| Certification: | ce |
| Model Number: | 2488H V7 |
| Minimum Order Quantity: | 1 pieces |
| Packaging Details: | BOX |
| Delivery Time: | 1-3days |
| Payment Terms: | L/C, T/T |
| Private Mold: | NO | Products Status: | Stock |
|---|---|---|---|
| Model Number: | 2488H V7 | Form Factor: | 2U Rack Server |
| Processor: | 2 Or 4 X 4th Gen Intel Xeon Scalable Processors With TDP Up To 350 W Per Processor | Chipset: | Emmitsburg PCH |
| Memory: | 64 X DDR5 DIMMs | ||
| Highlight: | 2288H V7 Rack Server,FusionServer 2488H V7 HUAWEI Storage Server,2288H V7 HUAWEI Storage Server |
||
2U rack server
2 or 4 x 4th Gen Intel® Xeon® Scalable processors with TDP up to 350 W per processor
Emmitsburg PCH
64 x DDR5 DIMMs
Hot-swappable drives configurations:
• 8 x front 2.5″ SAS/SATA drives
• 25 x front 2.5″ SAS/SATA drives
• 4 x front 2.5″ SAS/SATA drives and 8 x NVMe SSDs
Flash storage: 2 x M.2 SSDs, supporting hardware RAID
RAID 0, 1, 10, 1E, 5, 50, 6, or 60; supercapacitors for cache data protection from power failures;
RAID level migration, drive roaming, self-diagnosis, and remote web-based configuration
Multiple network expansion capabilities
1 x OCP 3.0 NIC, supporting hot swap
Up to 10 x PCIe slots, including 1 x FlexIO slot dedicated for the OCP 3.0 NIC and 9 x standard PCIe slots
6 x hot-swappable counter-rotating fans in N+1 redundancy
2 x hot-swappable Platinum/Titanium PSUs in 1+1 redundancy
• 900 W AC Platinum/Titanium PSUs (input: 100 V to 240 V AC, or 192 V to 288 V DC)
• 1500 W AC Platinum PSUs
850 W (input: 100 V to 127 V AC)
1500 W (input: 200 V to 240 V AC, or 192 V to 288 V DC)
• 1500 W 380 V HVDC PSUs (input: 260 V to 400 V DC)
• 1200 W -48 V to -60 V DC PSUs (input: -38.4 V to -72 V DC)
• 2000 W AC Platinum/Titanium PSUs
1800 W (input: 200 V to 220 V AC, or 192 V to 200 V DC)
2000 W (input: 220 V to 240 V AC, or 200 V to 288 V DC)
2150 W Titanium PSUs (input: 230 V to 240 V AC, or 230 V to 288 V DC)
• 3000 W AC Titanium PSUs
2500 W (input: 200 V to 220 V AC, or 192 V to 200 V DC)
2900 W (input: 220 V to 230 V AC, or 200 V to 230 V DC)
3000 W (input: 230 to 240 V AC, or 230 to 288 V DC)
The iBMC chip integrates one dedicated management GE network port, providing comprehensive management features such as fault diagnosis, automatic O&M, and hardware security hardening.
• The iBMC supports standard interfaces such as Redfish, SNMP, and IPMI 2.0, provides a remote management user interface based on HTML5/VNC KVM; supports out-of-band management functions such as monitoring, diagnosis, configuration, Agentless, and remote control for simplified management.
• It is optional to configure the FusionDirector management software that provides advanced management features such as five intelligent technologies, enabling intelligent, automatic, visualized, and refined management throughout the lifecycle.
FusionOS, Microsoft Windows Server, SUSE Linux Enterprise Server, VMware ESXi, Red Hat Enterprise Linux, Oracle, Ubuntu, and openEuler
Power-on password, administrator password, Trusted Platform Module (TPM) 2.0, security panel, secure boot, and chassis cover opening detection
5°C to 45°C (41°F to 113°F), compliant with ASHRAE Classes A1/A2/A3/A4
CE, UL, CCC, FCC, VCCI, and RoHS
L-shaped guide rails, adjustable guide rails, and holding rails
Chassis with 2.5″ drives: 86.1 mm x 447 mm x 898 mm (3.39 in. x 17.60 in. x 35.35 in.)
