| Place of Origin: | Beijing, China |
|---|---|
| Brand Name: | Dell |
| Certification: | CE ROHS 3C FCC |
| Model Number: | XT380 XT480 XT680 XT880 XT380F XT480F XT680F XT880F |
| Minimum Order Quantity: | 1 Piece |
| Packaging Details: | New Original Packing |
| Delivery Time: | 3-6 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 100 Piece/Pieces per Quarter |
| Products Status: | Stock | Brand Name: | Dell EMC |
|---|---|---|---|
| Model Number: | Unity XT380 Unity XT380 XT480 XT680 XT880 XT380F XT480F XT680F XT880F | Product Name: | Dell Unity Storage |
| Lead Time: | 1-3working Days | ||
| Highlight: | XT480 Dell Unity Storage,XT880F Dell Unity Storage,XT380 Dell Unity Storage |
||
| 380F/380 | 480F/480 | 680F/680 | 880F/880 | |
| Min/Max Drives | 6/500 | 6/750 | 6/1000 | 6/1500 |
| Array Enclosure | A 2U Disk Processor Enclosure (DPE) with twenty five 2.5” drives | |||
| Drive Enclosure (DAE - Disk Array Enclosure) | All-Flash (F) models support 2.5” drives in 2U twenty five drive and 3U eighty drive trays. Hybrid models support 2.5“ drives in 2U twenty five drive and 3U eighty drive trays; and 3.5” drives in 3U fifteen drive trays. |
|||
| Standby Power System | Dell EMC Unity systems are powered by 2 power supplies (PS) per DPE/DAE. Each power supply can provide power to the entire module if the peer PS has been removed or is faulted. DPE power during a power failure is provided by a Battery Back Up (BBU) module. BBU is located within the SP enclosure and provides power to a single module (power zone) |
|||
| RAID Options | 1/0, 5, 6 | |||
| CPU per Array | 2 x Intel CPUs, 12 cores per Array, 1.7GHz | 2 x dual-socket Intel CPUs, 32 cores per Array, 1.8GHz | 2 x dual-socket Intel CPUs, 48 cores per Array, 2.1GHz | 2 x dual-socket Intel CPUs 64 cores per Array, 2.1GHz |
| System Memory/Cache per Array | 128 GB | 192 GB | 384 GB | 768 GB |
| Max FAST Cache per Array* | Up to 800 GBs | Up to 1.2 TBs | Up to 3.2 TBs | Up to 6.0TBs |
| Total Cache* | Up to 928 GBs | Up to 1.39 TBs | Up to 3.58 TBs | Up to 6.76 TBs |
| Max Mezzanine cards per Array** | NA | 2 | 2 | 2 |
| Max IO Modules per Array*** | 4 | 4 | 4 | 4 |
| Embedded SAS IO Ports per Array | 4 x 4 lane 12Gb/s SAS ports for BE (back end) Connection | 4 x 4 lane 12Gb/s SAS ports for BE Connection | 4 x 4 lane 12Gb/s SAS ports for BE Connection | 4 x 4 lane 12Gb/s SAS ports for BE Connection |
| Optional SAS IO ports per Array | NA | 8 x 4 lane or 4 x 8 lane 12Gb/s SAS ports (for BE Connection) | 8 x 4 lane or 4 x 8 lane 12Gb/s SAS ports (for BE Connection) | 8 x 4 lane or 4 x 8 lane 12Gb/s SAS ports (for BE Connection) |
| Base 12 Gb/s SAS BE Buses per Array | 2 x 4 Lane | 2 x 4 Lane | 2 x 4 Lane | 2 x 4 Lane |
