| Place of Origin: | China |
|---|---|
| Brand Name: | Cisco |
| Certification: | CE |
| Model Number: | C9200-48T-A |
| Minimum Order Quantity: | 2 pieces |
| Packaging Details: | carton |
| Products Status: | Stock | Ports: | 48 |
|---|---|---|---|
| Default Primary AC Power Supply: | PWR-C5-125WAC | Stacking Bandwidth: | 160 Gbps |
| Product Name: | C9200-48T-A | Warranty: | 1 Year |
| Weight: | 5Kg | Port: | Beijing |
| Highlight: | 48 Port Switch Cisco Catalyst 9200,Manageable Switch Cisco Catalyst 9200,C9200-48T-A Cisco Manageable Switch |
||
| Downlinks total 10/100/1000 or PoE+ copper ports | 48 ports data |
| Uplink configuration | Modular uplink options |
| Default primary AC power supply | PWR-C5-125WAC |
| Fans | FRU redundant |
| Software | Network Advantage |
| Chassis Dimensions |
1.73 x 17.5 x 13.8 in 4.4 x 44.5 x 35.0 cm |
| Weight | 5.0 Kg |
| Virtual Networks | 4 |
| Stacking bandwidth | 160 Gbps |
| Total number of MAC addresses | 32,000 |
| Total number of IPv4 routes (ARP plus learned routes) | 14,000 (10,000 direct routes and 4,000 indirect routes) |
| IPv4 routing entries | 4,000 |
| IPv6 routing entries | 2,000 |
| Multicast routing scale | 1,000 |
| QoS scale entries | 1,000 |
| ACL scale entries | 1,600 |
| Packet buffer per SKU | 6 MB buffers for 24- or 48-port Gigabit Ethernet models |
| Flexible NetFlow (FNF) entries | 16,000 flows on 24- and 48-port Gigabit Ethernet models |
| DRAM | 4 GB |
| Flash | 4 GB |
| VLAN IDs | 4096 |
| Total Switched Virtual Interfaces (SVIs) | 1000 |
| Jumbo frames | 9198 bytes |
| Wireless bandwidth per switch | Up to 48 Gbps on 24-port and 48-port Gigabit Ethernet model |
| Switching capacity | 176 Gbps |
| Forwarding rate | 261.9 Mpps |
| Mean time between failures (hours) | 571,440 |
