| Brand Name: | H3C |
|---|---|
| Model Number: | R4900 G5 |
| Minimum Order Quantity: | 1 |
| Delivery Time: | 50pcs per week |
| Highlight: | OEM H3C Server,R4900 H3C Server,OEM h3c uniserver r4900 g5 |
||
|---|---|---|---|
The iFIST server hardware diagnosis function provides the following capabilities:
· Displays information about key hardware components on the server, such as the CPU, memory, PSU, fan, HDM, PCIe, NIC, and GPU.
· Runs fast diagnostic tests and stress tests on server hardware components such as the CPU, memory, PSU, fan, HDM, PCIe, NIC, and GPU.
· Displays the hardware test state and results on the iFIST Web interface.
· Exports the server hardware information and test results to a USB flash drive.
· Performs memory smart-test.
| Item | Specifications |
| Dimensions (H × W × D) |
· Without a security bezel: 87.5 × 445.4 × 748 mm (3.44 × 17.54 × 29.45 in) · With a security bezel: 87.5 × 445.4 × 776 mm (3.44 × 17.54 × 30.55 in) |
| Max. weight | 42.1 kg (92.81 lb) |
| Processors | 2 ×Intel Ice Lake processors, maximum 270 W power consumption per processor |
| Memory |
A maximum of 32 DIMMs Supports DDR4 and PMem 200 DIMMs |
| Storage controllers |
· Embedded VROC storage controller · High-performance standard storage controller · NVMe VROC module · Dual SD card extended module (supports RAID 1) |
| Chipset | Intel C621A Lewisburg chipset |
| Network connectors |
· 1 × embedded 1 Gbps HDM dedicated port · A maximum of 2 OCP 3.0 network adapter connectors (for NCSI-capable OCP 3.0 network adapters) |
| I/O connectors |
· 6 × USB connectors (two on the system board, two at the server rear, and two at the server front) · 12 × embedded SATA connectors: ¡ One ×8 SlimSAS connector ¡ One ×4 SlimSAS connector · 1 × RJ-45 HDM dedicated port (at the server rear) · 2 × VGA connectors (one at the server rear and one at the server front) · 1 ×serial port (at the server rear) · 1 × dedicated management interface (at the server front) |
| Expansion slots | 14 × PCIe 4.0 slots |
| Optical drives | External USB optical drives |
| Power supplies | 2 × hot-swappable power supplies, 1 + 1 redundancy |
| Standards | CCC, CECP, SEPA |
