| Place of Origin: | China |
|---|---|
| Brand Name: | Juniper |
| Certification: | CE |
| Model Number: | MX480 |
| Minimum Order Quantity: | 2 pcs |
| Packaging Details: | Carton |
| Delivery Time: | 5-8 work days |
| Payment Terms: | T/T |
| Supply Ability: | 70 PCS Per week |
| Products Status: | Stock | Brand: | Juniper |
|---|---|---|---|
| Products Name: | MX480 | Rack Units: | 8RU |
| Dimensions (W X H X D): | 44.5*35.6*60.5cm | Weight: | 81.7kg |
| Warranty: | 1 Year | Port: | Beijing |
| Highlight: | Routing Engine Juniper MX480,Rack-mountable Juniper MX480,Router Juniper MX480 |
||
| Main Specifications | |
|---|---|
| Dimensions & Weight / Depth | 60.5 cm |
| Dimensions & Weight / Height | 35.6 cm |
| Dimensions & Weight / Weight | 81.7 kg |
| Dimensions & Weight / Width | 44.5 cm |
| Header / Brand | Juniper Networks |
| Networking / Connectivity Technology | Wired |
| Networking / Form Factor | Rack-mountable |
| Networking / Type | Router |
| Packaged Quantity | 1 |
| Dimensions & Weight | |
| Depth | 60.5 cm |
| Height | 35.6 cm |
| Weight | 81.7 kg |
| Width | 44.5 cm |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 90% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Expansion / Connectivity | |
| Expansion Slots | 8 expansion slot |
| Installed Modules Qty (Max) | 8 (max) |
| Interfaces |
|
| General | |
| Compliant Standards | ETSI, EN 60950, EN 61000-3-2, VCCI Class A ITE, EN 61000-3-3, EN55022 Class A, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EMC, CSA C22.2 No. 60950-00, EN 61000-4-5, UL 1950 Third Edition, EN 61000-4-11, RoHS, FCC Part 15 A, NEBS, EN 60825-1, AS/NZS 3548 Class A |
| Connectivity Technology | Wired |
| Device Type | Router |
| Enclosure Type | Rack-mountable - modular - 8U |
| Features | Modular design, layer 3 switching, layer 2 switching, VPN support, MPLS support, manageable, High Availability, MPLS Fast Reroute (FRR), Quality of Service (QoS), midplane |
| Flash Memory | 1 GB |
| Hard Drive | 40 GB |
| Performance |
|
| Processor | 1 x 2 GHz |
| RAM | 4 GB |
| Remote Management Protocol | SNMP 2, SNMP 3, HTTP |
| Routing Protocol | BGP, GRE |
| Status Indicators | Status |
| Power | |
| Installed Qty | 4 (max) |
| Power Device | Internal power supply |
| Power Redundancy | Yes |
| Voltage Required | AC 120/230 V (50/60 Hz) |
