| Form Factor / Depth: | 2U / 764mm (30") | Processor: | 4th Generation AMD EPYC™ Processor Or 5th Generation AMD EPYC™ Processor |
|---|---|---|---|
| Memory: | 12x TruDDR5 DIMM Slots (1.5TB Max Using 128GB 3DS RDIMMs) | Drive Bays: | Up To 20x 3.5” Or 40x 2.5” Drives (hot-swap Drive Bay Combinations - SAS/SATA, NVMe, Or AnyBay™) |
| GPU Supports: | Up To 3x Double Width GPU Up To 8x Single Width GPU | RAID Support: | Hardware RAID Flash Cache; HBAs |
| Power Supply: | Dual Redundant PSUs Titanium/Platinum (meets ErP Lot 9 Standards) | Network Interface: | OCP 3.0 Mezz Adapter, PCIe Adapters |
| Slots: | Up To 10x PCIe Slots (10x Rear, Or 6x Rear + 2x Front) OCP 3.0 Adapter Slot PCIe Gen 4/Gen 5 And CXL Support | Systems Management: | ASPEED 2600, XClarity Support |
| Highlight: | 5th Gen AMD EPYC™ Processor Lenovo Rack Server,1.5TB TruDDR5 Memory Lenovo ThinkSystem SR655 V3,40x 2.5” Hot-Swap Drives 2U Server |
||
| Form Factor / Depth | 2U / 764mm (30") |
|---|---|
| Processor | 4th Generation AMD EPYC™ Processor or 5th Generation AMD EPYC™ Processor |
| Memory | 12x TruDDR5 DIMM slots (1.5TB Max using 128GB 3DS RDIMMs) |
| Drive Bays | Up to 20x 3.5" or 40x 2.5" drives (hot-swap drive bay combinations - SAS/SATA, NVMe, or AnyBay™) |
| GPU Support | Up to 3x double width GPU or 8x single width GPU |
| RAID Support | Hardware RAID flash cache; HBAs |
| Power Supply | Dual redundant PSUs Titanium/Platinum (meets ErP Lot 9 standards) |
| Network Interface | OCP 3.0 mezz adapter, PCIe adapters |
| Slots | Up to 10x PCIe slots (10x rear, or 6x rear + 2x front) OCP 3.0 adapter slot PCIe Gen 4/Gen 5 and CXL support |
| Ports | Front: USB 3.0 (5 Gbps) USB 2.0 (480 Mbps) Optional: VGA Rear: 3x USB 3.1 (5 Gbps) Serial port Ethernet management |
| Systems Management | ASPEED 2600, XClarity support |
